drylin W WSX double rail

WSX-10-40 product image

WSX-10-40 technical drawing

1 from 2

WSX-10-40 product image

WSX-10-40 technical drawing

Part No.

WSX-10-40

size

10-40

b [mm]

Slot nuts for mounting:

Part No.	Suitable for rail profile	Linear module
NOR-20602	WSX-06-30, WSX-06-60	SAW-0630, SAWC-0630, SAW-0660, ZLW-0630
NOR-20602	WSX-10-40	SAW-1040, SAWC-1040, ZLW-1040
NOR-20602	WSX-10-80	SAW-1080, ZLW-1080
NOR-20602	AWMQ-12/20	QWE-01-12, QWE-01-20
NOR-20602	WSX-16-60	SAW-1660, ZLW-1660 (lateral grooves)
NOR-20605	WSX-16-60	SAW-1660, ZLW-1660 (lower groove)

NOR-20613*
* Optionally available: Retractable utility block (M4) for retrofitting

Here you will find suitable Clamping elements for linear modules and toothed belt axes
